Print Bridge

Print common email attachments directly to a network printer — fully inside Home Assistant.

Print Bridge turns an email inbox, Signal conversation, or local folder into a controlled print intake. It listens to Home Assistant's built-in IMAP events, receives approved Signal document attachments, or scans a configured queue folder, fetches printable documents, converts supported types to an internal PDF, merges related attachments into one job, applies duplex/booklet rules, and submits the result to CUPS or directly to an IPP/AirPrint printer.

It was built because Home Assistant has the pieces but not the end-to-end printing workflow:

The built-in IMAP integration can announce new mail, but it does not convert attachments, manage print policy, or submit jobs to a printer.
The built-in IPP integration monitors printers; it does not send Print-Job requests.
Generic automations become fragile for real mail printing: attachment payloads can be large, filenames can be MIME-encoded, printers may reject PDF and need raster conversion, booklet jobs need page imposition, and busy printers need retry logic.

Print Bridge is the missing glue: one local integration that owns the print pipeline, exposes HA entities and services, keeps audit history, and lets normal Home Assistant automations stay simple.

Supported platforms

Platform	Supported	Notes
Home Assistant OS	✅	Recommended — full mDNS discovery, all features
Home Assistant Supervised	✅	Full support on any Linux host
Home Assistant Container (`--network=host`)	✅	Host networking required for mDNS
Home Assistant Core (Linux)	✅	mDNS works if the host has Avahi/Bonjour
Docker (bridge network)	⚠️	mDNS discovery limited — type IPP URL manually

mDNS printer discovery runs on the HA host and requires multicast packets to reach the HA process. Docker bridge networking blocks multicast, so auto-discovery will not find LAN printers. You can still configure a printer manually by typing its IPP URL.

Use Cases

Use case	Why Print Bridge helps
Email-to-printer mailbox	Forward documents to a dedicated mailbox such as `print@example.com`; matching attachments print automatically.
Signal-to-printer with confirmation	Receive documents by Signal from trusted contacts or groups, then print only after approving the pending job.
Folder-to-printer drop box	Put files in the configured queue folder and Print Bridge prints them even when no IMAP integration exists.
Family or office shared printing	Allow trusted senders only, while keeping printer access inside Home Assistant.
Weekly newsletters and parasha sheets	Match sender, subject, folder, or filename; print regular PDFs automatically without opening a laptop.
Booklets and folded handouts	Detect filename patterns or mail parameters, reorder pages for saddle-stitch booklet printing, force short-edge duplex, and request landscape fitting.
Invoices, bank letters, receipts	Print selected senders one-sided or duplex, then mark mail as read, move it to an archive folder, or leave it untouched.
Multiple attachments in one email	Convert and merge matching attachments into one job so the printer receives fewer submissions and prints faster.
Direct AirPrint printer without CUPS	Send IPP directly to modern printers; when PDF is not supported, convert internally to PWG Raster or JPEG.
Legacy or USB printer via CUPS	Let CUPS handle drivers while Print Bridge handles mail rules, queueing, conversion, audit, and Home Assistant controls.
Quiet-hours printing	Hold jobs outside allowed days/hours or a custom HA template gate, then flush them when the window opens.
Unreliable/busy printers	Queue jobs when the printer reports `server-error-busy`, poll readiness, and resend when it is available.
Status feedback to sender	Reply with success/failure, IPP status code, and the effective settings used for the job.

Why a Dedicated Integration?

This is intentionally not just an automation blueprint. A blueprint can route an event, but it cannot safely own the whole print lifecycle. Print Bridge needs to decode MIME filenames, fetch large attachments on demand, convert common file types, merge PDFs, impose booklets, query printer capabilities, translate to a printer-supported document format, poll and retry busy printers, record audit events, expose queue state, and optionally reply to the original sender.

Keeping that logic in a custom integration gives Home Assistant a clear boundary: IMAP still owns mail credentials, CUPS or the printer still owns physical printing, and Print Bridge owns the policy and transformation layer between them.

Features


Email event-driven	Triggered instantly by HA's IMAP push (IDLE) — no mailbox polling
Signal intake with confirmation	Receives Signal document attachments from a signal-cli-rest-api style module, filters trusted senders/groups, and waits for approval before printing
Queue folder intake	Automatically prints supported files dropped in the configured queue folder; IMAP is optional
Smart setup	Auto-discovers CUPS printers; pre-fills sender from existing IMAP accounts
Sender filter	Accept only specific email addresses, or leave empty to accept all
Folder filter	Accept only emails arriving in specific IMAP folders (e.g. `INBOX/Print`)
Common document support	Prints PDF, DOCX/DOCM, ODT, RTF, TXT, HTML, Markdown, XLS/XLSX/ODS/CSV/TSV, PPTX/ODP, and common image files
Combined email jobs	Converts and merges matching attachments from one email into one print job for faster batches
Duplex control	One-sided, long-edge (portrait), or short-edge (landscape) per job or globally
Booklet printing	Automatic saddle-stitch page reordering for filenames matching a pattern
Audit log	Every print job fires `print_bridge_job_completed` → appears in HA Logbook
Job history sensor	Last 50 jobs with sender, duplex, timestamp as attributes
Filter preview	Press a button to scan the mailbox and see which emails would be printed
One-press mail printing	Dashboard buttons print the latest five matching mailbox emails
Mailbox/printer selectors	Dashboard selects choose which IMAP account to scan and which printer receives manual jobs
Dashboard configuration	Switch/select/text entities let Lovelace manage filters, duplex, cleanup, notifications, and schedule settings
Scheduled printing	Hold jobs outside allowed days, hours, or a custom HA template gate
Printer-busy retry queue	If IPP returns `server-error-busy`, poll readiness and resend automatically
Queued job view/cancel	Dashboard shows up to five scheduled, Signal-pending, or printer-busy jobs and can discard queued work before submission
Blueprint	Advanced per-sender/per-keyword rules with folder, duplex, and booklet logic
Lovelace dashboard	Paste-ready printer view plus detailed audit view
Services	`print_file`, `clear_queue`, `process_imap_message`, `process_imap_part`, `check_filter`, `print_email`, `confirm_signal_job`, `cancel_signal_job`, `check_signal_groups`

Prerequisites

HA integrations — what is and isn't needed

Integration	Required?	Role
HA IMAP (built-in)	Optional	Required only for email automation. Without IMAP, Print Bridge can still print files from the queue folder or via `print_file`.
Signal REST module	Optional	Required only for Signal document intake. Use a signal-cli-rest-api compatible module, configured by URL and Signal account/number.
HA IPP (built-in)	No	Monitors printer status (ink, paper, errors). Print Bridge does not use it — Print Bridge is its own IPP client and sends `Print-Job` packets directly.
CUPS add-on	Optional	Needed for USB printers or non-AirPrint printers that require driver conversion. AirPrint printers can be reached directly via IPP.

Why not the HA IPP integration? HA's built-in ipp integration (docs) is a monitoring tool — it reads printer state, ink levels, and page counts. Print Bridge speaks raw IPP/2.0 directly to the printer or CUPS server and submits Print-Job requests. You can install both side-by-side: use the HA IPP integration to monitor ink/status, and Print Bridge to receive and dispatch print jobs.

Print Bridge also uses Get-Printer-Attributes itself when needed to discover supported document formats and to decide when a busy direct IPP printer is ready for the next queued job.

1. HA IMAP Integration (built-in) — optional for email printing

Settings → Devices & Services → Add Integration → IMAP

Configure it with your mail server details. Print Bridge listens to the imap_content events it fires — no credentials are stored in Print Bridge. Skip this step if you only want to print files dropped into the queue folder.

2. Printer — required; choose one

Option A — Direct IPP (no extra software needed)

Any WiFi printer with AirPrint support (manufactured after ~2012) has a built-in IPP server. Print Bridge can send jobs directly to the printer's endpoint, for example:

http://printer.local/ipp/print        (standard AirPrint path)
http://printer.local:631/ipp/print    (CUPS-style port)

No add-ons, no CUPS required. Set this URL in the Direct IPP Printer URL field during setup.

Option B — Via CUPS (for USB or legacy printers)

The recommended option for HA OS is the CUPS add-on by peternicholls:

Settings → Add-ons → Add-on Store → add repository https://github.com/peternicholls/ha-cups-addon
Install CUPS Print Server and start it.
Open the CUPS web UI at http://<ha-host>:631 → add your printer.
Note the queue name shown in the CUPS Printers list.

Installation

HACS (recommended)

Click the button below to open Print Bridge directly in HACS:

Or add it manually: HACS → Integrations → ⋮ → Custom repositories → add https://github.com/rubeecube/ha-print-bridge (category Integration) → search Print Bridge → install → restart HA.

After installation — open the config flow

Once installed (via HACS or manually), click here to add the integration to your HA instance:

Manual (without HACS)

Copy custom_components/print_bridge/ into your HA config directory and restart:

/config/custom_components/print_bridge/

Configuration

Step 1 — Optional HA IMAP Integration

Configure the built-in IMAP integration first only if you want email-triggered printing (see Prerequisites).

Step 2 — Add Print Bridge

Settings → Devices & Services → Add Integration → Print Bridge

The setup wizard auto-discovers both CUPS and direct IPP printers at common addresses and lists any IMAP accounts already configured in HA.

Option A — Direct IPP (no CUPS required)

For any AirPrint / IPP-capable printer on your network (including most Canon PIXMA with AirPrint), you can print directly without CUPS:

Field	Example
Direct IPP Printer URL	`http://printer.local/ipp/print` or `ipp://printer.local/ipp/print`

The integration sends an IPP Print-Job packet directly to the printer. Modern AirPrint printers usually accept PDF natively; if a direct IPP printer advertises only PWG Raster or JPEG, Print Bridge converts the internal PDF to the accepted format before submission. Leave the CUPS fields empty.

Option B — Via CUPS

Field	Example	Description
CUPS Base URL	`http://cups.local:631`	Auto-filled if CUPS is found; edit if on a different host
Printer Name	`Canon_MG3600_series`	Select from discovered printers, or choose Enter name manually…

Use CUPS when: the printer is USB-attached, needs driver/raster conversion, or you want a managed print queue.

3. Signal REST Module — optional for Signal printing

Signal printing is disabled by default and is confirmation-only. It stays disabled until the configured signal-cli-rest-api compatible receiver answers successfully for the Signal REST URL and account in Print Bridge options:

Field	Description
Signal Module ID	Defaults to `019ef0ac-4dcf-72b2-b5ec-3ff077450a00`.
Signal REST URL	Base URL of the Signal REST module, for example `http://homeassistant.local:8080`.
Signal Account / Number	Registered Signal account used by the module.
Signal Allowed Senders	Trusted Signal phone numbers or UUIDs, one per line.
Signal Allowed Groups	Trusted Signal group IDs or exact group names, one per line. Print Bridge resolves names through Check Signal Groups; duplicate names are not trusted.
Signal Confirmation Mode	`Home Assistant and Signal` by default. Pending jobs can be confirmed from HA or by replying `print <token>` in Signal.
Default Print Type	Named profile used for new pending Signal jobs.
Custom Print Types	Optional profile lines, such as `weekly=booklet=true copies=2 media=a4`.

For group printing, exact IDs are still the safest filter. Group names are accepted for convenience; Print Bridge resolves them through the Signal REST group list and ignores duplicate names instead of guessing.

Common to both modes

Field	Description
Pre-fill Senders from	Optional — pre-loads an IMAP account's address into Allowed Senders

Options (editable any time)

Settings → Devices & Services → Print Bridge → Configure

The form shows a live hint: "Your IMAP integrations monitor: INBOX (print@example.com)" so you know which exact folder names to use.

Option	Default	Description
Allowed Senders	(empty = all)	One email address per line. Empty accepts mail from any sender.
IMAP Folder Filter	(empty = all)	One folder name per line. Empty accepts mail from any folder. Use the exact name shown in the hint above (e.g. `INBOX`, `INBOX/Print`).
Default Duplex Mode	Two-sided portrait	Fallback for all jobs.
Booklet Patterns	(empty)	Filename substrings that trigger booklet page reordering.
Delete after printing	On	Remove successfully printed queue-folder files. If off, printed files are remembered and not reprinted unless modified.
Print Queue Folder	`/media/print_queue`	Drop supported files here for folder-to-printer intake. Also used by the queue-depth sensor and `clear_queue`.
Raster DPI	`150`	Used only when direct IPP printing must convert PDFs to PWG Raster/JPEG. Lower values are faster and create smaller jobs.
Default Print Type	Normal	Named profile used for pending Signal jobs before confirmation. Built-ins: `normal`, `simplex`, `duplex`, `booklet`, `draft`.
Custom Print Types	(empty)	Optional profile lines. Example: `weekly=booklet=true copies=2 media=a4`.
Enable Signal intake	Off	Receive Signal document attachments from the configured module. Runtime intake remains off until the configured Signal REST URL/account answer successfully. Nothing prints automatically; each received document waits for confirmation.
Signal Module ID	`019ef0ac-4dcf-72b2-b5ec-3ff077450a00`	Identifier of the Signal module used by this integration.
Signal REST URL	(empty)	Base URL for the signal-cli-rest-api compatible module.
Signal Account / Number	(empty)	Signal account registered in the module.
Signal Allowed Senders	(empty = none)	Trusted Signal phone numbers or UUIDs. Unlike email, empty means no Signal sender is trusted.
Signal Allowed Groups	(empty = none)	Trusted Signal group IDs or exact group names. Empty means no Signal group is trusted. Duplicate names are ignored until you use an exact group ID.
Signal Confirmation Mode	Home Assistant and Signal	Confirm pending jobs from HA, Signal replies, or both.
Signal Confirmation TTL	`24`	Pending Signal job expiration in hours.
Email Action after Printing	Do nothing	What to do with the email after the PDF prints: Do nothing / Mark as read / Move to archive folder / Delete from server.
Archive Folder	`INBOX/Printed`	Target folder when "Move to archive folder" is selected. Created automatically by most IMAP servers.
Notify when print fails	On	Send a HA persistent notification when a job fails (with error details).
Notify when print succeeds	Off	Send a HA persistent notification when a job completes successfully.
Reply to sender with print status	Off	Send a status email to the original sender after printing. Requires an email-capable HA notify service.
Status Reply Notify Service	(empty)	Notify service used for status replies, for example `notify.smtp`.
Enable print schedule	Off	Hold matching jobs in the scheduled queue until the configured day, hour, and template gates are open.
Print window start/end	`07:00` / `22:00`	Allowed local print hours in 24-hour `HH:MM` format. Windows can wrap midnight.
Print days	(every day)	Optional weekday list. Use `mon`, `tue`, full names, or `1`-`7`; one per line or comma-separated.
Print schedule template	(empty)	Optional HA template. Jobs print only when it renders truthy (`true`, `on`, `yes`, or `1`). Available variables include `now`, `schedule_time`, `schedule_weekday`, `schedule_window_day`, `schedule_days`, `schedule_start`, `schedule_end`, and `printer_name`.

After Setup — Where to find everything

After configuring the integration you will see a notification: "Print Bridge — Action required" — follow the links in it, then dismiss it.

1. Find your entities

Settings → Devices & Services → Integrations → Print Bridge → click the device card

All sensors, buttons, and binary sensors appear here. You can press Check Filter directly from this page to scan your mailbox.

2. Add the management dashboard

For the easiest setup, copy lovelace/printer_dashboard_template.yaml from the repo into a new dashboard view:

Your Dashboard → Edit → Add View → Manual configuration (YAML) → paste the file contents

Replace YOUR_SLUG with the entity slug shown in Developer Tools → States when you search "print_bridge" (e.g. canonmg3600series).

The simple template includes component configuration controls, mailbox/printer selectors, status tiles, and print actions. The detailed audit view remains available at lovelace/print_bridge_audit.yaml.

3. Choose your printing mode

Use the dashboard Auto Print switch:

On — simple setup; Print Bridge prints supported attachments from allowed senders and supported files from the queue folder automatically.
Off — use the automation blueprint for per-sender / per-keyword rules.

4. Enable debug logging (troubleshooting)

Add to configuration.yaml:

logger:
  logs:
    custom_components.print_bridge: debug

Then go to Settings → System → Logs to view debug output. This shows each discovery step, event received, and print job stage.

Entities

Entity	Type	State	Key attributes
`sensor.print_bridge_*_print_queue_depth`	Sensor	File count	—
`sensor.print_bridge_*_last_print_job`	Sensor	`success` / `failed`	`last_filename`, `last_status`, `sender`, `duplex`, `booklet`, `source_format`, `converted_format`, `attachments`, `skipped_attachments`, `timestamp`
`sensor.print_bridge_*_job_log`	Sensor	Total jobs sent	`jobs[]` — last 50 print attempts with full metadata
`sensor.print_bridge_*_filter_preview`	Sensor	Matching emails with printable attachments	`emails[]`, `checked_at`, `imap_account`, `total_found`, `matching_filter`, `with_pdf`, `with_printable`
`sensor.print_bridge_*_scheduled_queue`	Sensor	Queued job count	`jobs[]` shows up to 5 schedule-held or printer-busy jobs, plus `total_jobs`, `schedule_jobs`, `printer_busy_jobs`, `shown_jobs`, schedule settings
`sensor.print_bridge_*_signal_pending_jobs`	Sensor	Pending Signal jobs	`jobs[]` shows up to 5 waiting Signal confirmation jobs with token, sender/group, attachments, and expiry
`sensor.print_bridge_*_signal_groups`	Sensor	Discovered Signal group count	`groups[]` with exact group IDs from Check Signal Groups
`binary_sensor.print_bridge_*_printer_online`	Binary Sensor	`on` / `off`	—
`select.print_bridge_*_imap_account`	Select	Selected IMAP account	Used by Check Filter and on-demand email printing when no account is specified
`select.print_bridge_*_target_printer`	Select	Selected printer	Used by dashboard print actions and default print services
`select.print_bridge_*_default_duplex_mode`	Select	Duplex mode	Updates the default duplex option
`select.print_bridge_*_email_action_after_print`	Select	Email action	Updates post-print mailbox cleanup behavior
`select.print_bridge_*_signal_confirmation_mode`	Select	Signal confirmation mode	Controls whether HA, Signal replies, or both can confirm jobs
`switch.print_bridge__`	Switch	`on` / `off`	Auto-print, delete-after-printing, notifications, and schedule enablement
`text.print_bridge__`	Text	Current value	Sender/folder filters, booklet patterns, queue/archive folders, and schedule fields
`button.print_bridge_*_print_test_page`	Button	—	Sends a built-in one-page PDF to the printer
`button.print_bridge_*_check_filter`	Button	—	Scans the mailbox and updates `filter_preview` sensor
`button.print_bridge_*_check_signal_groups`	Button	—	Queries the Signal REST module and updates `signal_groups` sensor
`button.print_bridge__confirm_signal_`	Button	—	Confirms one of the first five pending Signal document jobs
`button.print_bridge_*_cancel_queued_jobs`	Button	—	Cancels schedule-held jobs, printer-busy retry jobs, and queued PDFs that have not been submitted

* is a slug derived from the printer's CUPS queue name.

Services

Supported files

Print Bridge converts supported non-PDF inputs to an internal PDF before the existing booklet, CUPS/direct IPP, raster, status reply, queue, and audit pipeline runs. Conversion is best effort: readable content, basic tables, sheet names, slide text, and image pages are preserved, but Office-perfect pagination, macros, charts, embedded objects, headers/footers, and complex layout are not guaranteed.

Supported: .pdf, .docx, .docm, .odt, .rtf, .txt, .html, .htm, .md, .xlsx, .xlsm, .xls, .ods, .csv, .tsv, .pptx, .odp, .jpg, .jpeg, .png, .tif, .tiff, .bmp, .webp.

Explicitly unsupported: legacy binary .doc and .ppt files. These need an external office engine such as LibreOffice, which Print Bridge does not bundle.

Queue folder intake

When Auto Print is enabled, Print Bridge also scans the configured Print Queue Folder. Any stable supported file found there is printed through the same conversion, booklet, direct IPP/CUPS, busy-printer retry, audit, and notification pipeline as email attachments.

Temporary or hidden files are ignored. Successfully printed files are deleted when Delete after printing is enabled. If deletion is disabled, each file is printed once per modification time and will not repeat until it changes.

`print_bridge.print_file`

Print a supported file from the HA filesystem. Non-PDF files are converted to an internal PDF first.

Field	Required	Description
`file_path`	yes	Absolute path to the supported file
`duplex`	no	Override duplex for this job
`booklet`	no	Force booklet page reordering
`copies`	no	Number of copies, 1-20
`collate`	no	Collate multi-copy jobs; default is `true`
`orientation`	no	`portrait` or `landscape`; booklet jobs force `landscape`
`media`	no	IPP media keyword, such as `iso_a4_210x297mm`
`raster_dpi`	no	Direct IPP raster conversion DPI, 72-600. Lower is faster; default is `150`.

`print_bridge.clear_queue`

Delete all supported printable files from the configured queue folder.

`print_bridge.process_imap_part`

Fetch a specific IMAP attachment and print it. Used internally by the blueprint; callable from any automation or script.

Field	Required	Description
`entry_id`	yes	IMAP config entry ID (`trigger.event.data.entry_id`)
`uid`	yes	Email UID (`trigger.event.data.uid`)
`part_key`	yes	Part key from `trigger.event.data.parts`
`filename`	no	Display name for the print job
`duplex`	no	Override duplex for this job
`booklet`	no	Force booklet page reordering
`attachment_filter`	no	Only print if the filename contains this text
`attachment_ignore_filter`	no	Skip filenames containing any of these comma/semicolon-separated substrings
`allowed_extensions`	no	Only print these extensions, for example `pdf docx jpg`
`ignored_extensions`	no	Skip these extensions, for example `png tiff`
`copies`	no	Number of copies, 1-20
`collate`	no	Collate multi-copy jobs; default is `true`
`orientation`	no	`portrait` or `landscape`; booklet jobs force `landscape`
`media`	no	IPP media keyword, such as `iso_a4_210x297mm`
`raster_dpi`	no	Direct IPP raster conversion DPI, 72-600. Lower is faster; default is `150`.
`sender`	no	Original email sender, used for status replies
`mail_subject`	no	Original email subject, used for mail parameters and reply title
`mail_text`	no	Original plain-text email body, used for mail parameters

`print_bridge.process_imap_message`

Fetch all supported attachments from an IMAP message, convert them to PDF, merge them in email attachment order, and submit one print job. This is the default path used by the bundled blueprint because it is faster when one email has multiple attachments.

Field	Required	Description
`entry_id`	yes	IMAP config entry ID (`trigger.event.data.entry_id`)
`uid`	yes	Email UID (`trigger.event.data.uid`)
`parts`	no	Parts dictionary from `trigger.event.data.parts`; avoids one metadata fetch
`duplex`	no	Override duplex for this job
`booklet`	no	Force booklet page reordering
`attachment_filter`	no	Only include attachment filenames containing this text
`attachment_ignore_filter`	no	Skip filenames containing any of these comma/semicolon-separated substrings
`allowed_extensions`	no	Only include these extensions, for example `pdf docx jpg`
`ignored_extensions`	no	Skip these extensions, for example `png tiff`
`copies`	no	Number of copies, 1-20
`collate`	no	Collate multi-copy jobs; default is `true`
`orientation`	no	`portrait` or `landscape`; booklet imposition is landscape
`media`	no	IPP media keyword, such as `iso_a4_210x297mm`
`raster_dpi`	no	Direct IPP raster conversion DPI, 72-600. Lower is faster; default is `150`.
`sender`	no	Original email sender, used for status replies
`mail_subject`	no	Original email subject, used for mail parameters and reply title
`mail_text`	no	Original plain-text email body, used for mail parameters

`print_bridge.print_email`

Print all supported attachments from a specific email in your mailbox as one combined job — on demand, without waiting for the email to arrive again. Get the UID from the Lovelace email table or the filter_preview sensor.

Field	Required	Description
`uid`	yes	IMAP UID of the email (shown in the Lovelace email table)
`imap_entry_id`	no	IMAP config entry ID — defaults to the first configured account
`duplex`	no	Override duplex for this job
`booklet`	no	Force booklet page reordering
`attachment_filter`	no	Only print matching attachment filenames
`attachment_ignore_filter`	no	Skip filenames containing any of these comma/semicolon-separated substrings
`allowed_extensions`	no	Only print these extensions, for example `pdf docx jpg`
`ignored_extensions`	no	Skip these extensions, for example `png tiff`
`copies`	no	Number of copies, 1-20
`collate`	no	Collate multi-copy jobs; default is `true`
`orientation`	no	`portrait` or `landscape`; booklet jobs force `landscape`
`media`	no	IPP media keyword, such as `iso_a4_210x297mm`
`raster_dpi`	no	Direct IPP raster conversion DPI, 72-600. Lower is faster; default is `150`.

Signal services

Signal intake creates pending jobs only. A received Signal document is printed after one of these confirmation paths succeeds:

Service	Description
`print_bridge.confirm_signal_job`	Confirm and print a pending Signal job by `job_id` or `token`.
`print_bridge.cancel_signal_job`	Cancel a pending Signal job by `job_id` or `token`.
`print_bridge.check_signal_groups`	Query the Signal REST module and expose exact group IDs in the Signal Groups sensor.

Signal reply commands are available when confirmation mode includes Signal:

set <token> type=booklet copies=2
print <token>
print <token> type=booklet copies=2
cancel <token>

set updates the pending job and replies with the new effective settings without printing. print may include final inline overrides; invalid values are rejected and the job remains pending.

Each confirmed Signal job uses the same conversion, merge, booklet, reverse order, collate, direct IPP/CUPS, busy-printer retry, audit, and notification pipeline as email and folder jobs.

Signal print types

Signal pending jobs start with the configured Default Print Type and can be adjusted before confirmation.

Built-in print types:

Type	Settings
`normal`	Current integration defaults and booklet filename patterns
`simplex`	One-sided, not booklet
`duplex`	Two-sided long-edge, not booklet
`booklet`	Booklet, short-edge duplex, landscape
`draft`	One-sided, not booklet, fast raster DPI

Add custom types in Custom Print Types, one per line:

weekly=booklet=true copies=2 media=a4
receipt=duplex=one-sided reverse=true

Mail print parameters

Allowed senders can include per-email print settings in the subject or body. These override the integration defaults and blueprint/service values for that email. If Allowed Senders is empty, normal auto-printing can still accept all senders, but mail-body configuration commands and overrides are ignored.

Subject form:

[pb booklet=true duplex=short-edge copies=2 paper=a4 dpi=150 reply=true]

Body form:

Print-Bridge: attachment="Au Puits"; orientation=landscape; paper=a4; quality=fast

Copies can also be requested with nb_copies=3, copy=3, or a body that only contains 3.

To get a ready-to-edit configuration template by email, an allowed sender can send a message with no attachment and:

Print-Bridge: config

Print Bridge replies with a Print-Bridge: line containing the current defaults. Reply to that email, adjust the values, attach documents, and the retained line is used as the override for that print.

Supported parameters:

Parameter	Values
`duplex` / `sides`	`one-sided`, `simplex`, `long-edge`, `short-edge`, `two-sided-long-edge`, `two-sided-short-edge`
`booklet`	`true` / `false`
`copies` / `nb_copies` / `copy`	`1` through `20`
`collate`	`true` / `false`; default is `true`
`orientation`	`portrait` / `landscape`; booklet jobs always request landscape
`paper` / `media`	`a4`, `letter`, `legal`, or a raw IPP media keyword
`dpi` / `raster_dpi`	`72` through `600`; only used when direct IPP requires raster conversion
`quality`	`draft`, `fast`, `normal`, `high`, or `best` (`fast` maps to 150 DPI)
`attachment` / `attachment_filter` / `file`	Filename substring to print only matching attachments
`attachment_ignore_filter` / `ignore_filename` / `skip_filename`	Filename substring list to skip matching attachments
`allowed_extensions` / `only_extensions` / `include_extensions`	Extension allow-list, such as `pdf docx jpg`; dots are optional
`ignored_extensions` / `ignore_extensions` / `skip_extensions`	Extension deny-list, such as `png tiff`; dots are optional
`reply` / `status_reply`	`true` to request a status reply, `false` to suppress one
`reverse` / `reverse_order` / `order`	`true`, `false`, `reverse`, or `normal` for one-sided page order
`type` / `print_type` / `profile`	Named Signal print type, such as `normal`, `booklet`, or a custom type
`config` / `command=config`	Reply with all configurable mail parameters when no printable attachment is present

Boolean values are case-insensitive and accept true/false, yes/no, on/off, and 1/0. Invalid values fail the job and return a status reply instead of silently printing with the wrong settings.

Status replies include the IPP status code plus the effective printer settings used for each job. Print Bridge uses the configured Home Assistant notify service when set (for example notify.smtp); otherwise it attempts SMTP delivery through the matching HA IMAP account.

From Developer Tools → Services:

service: print_bridge.print_email
data:
  uid: "42"
  duplex: two-sided-long-edge

From an automation, after check_filter:

action: print_bridge.print_email
data:
  uid: "{{ state_attr('sensor.print_bridge_PRINTER_NAME_filter_preview', 'emails')[0].uid }}"

`print_bridge.check_filter`

Connect to IMAP and list emails that match the current filter settings. Returns a service response and updates sensor.print_bridge_*_filter_preview.

Field	Required	Description
`imap_entry_id`	no	Which IMAP entry to query (defaults to first configured)

Audit Log

Every print attempt fires an print_bridge_job_completed event to the HA event bus. This event appears in the native HA Logbook as a human-readable sentence:

Print Bridge — Printed invoice.pdf · two-sided-long-edge · from billing@example.com · Canon_MG3600_series

Print Bridge — Print failed for bad.pdf: HTTP 503 · from sender@example.com

The sensor.print_bridge_*_job_log entity stores the last 50 jobs as attributes, including timestamp, filename, success/failure, sender, duplex mode, and booklet flag. It also stores the effective IPP sides, document format, status code, copies, orientation, media, and raster DPI when available.

How it works

Mail Server ──IMAP IDLE──► HA IMAP Integration ──imap_content event──► Print Bridge
                                                                              │
                          1. Check sender, folder, subject, and schedule      │
                          2. Detect supported attachment filenames/types      │
                          3. Fetch attachment bytes via imap.fetch_part ◄─────┘
                          4. Convert non-PDF files to internal PDF
                          5. Merge matching attachments into one job
                          6. Mail parameters override duplex/booklet/copies/media/dpi
                          7. Booklet? → impose pages + request landscape/fit
                          8. Query printer formats when direct IPP needs it
                          9. Build IPP/2.0 packet → POST to CUPS/printer
                         10. Busy? queue, poll readiness, resend
                         11. Fire print_bridge_job_completed → Logbook/status reply

Blueprint — Advanced Per-Email Rules

For fine-grained per-sender or per-keyword rules (different duplex per sender, booklet for some subjects, multiple printers), use the included automation blueprint.

Import

Settings → Automations → Blueprints → Import Blueprint — paste:

https://github.com/rubeecube/ha-print-bridge/blob/main/blueprints/automation/print_bridge/print_from_email.yaml

Inputs

Input	Default	Description
IMAP Account	—	Which IMAP integration entry to monitor
Sender	(all)	Optional sender substring
Subject contains	(all)	Optional keyword gate on the subject line
Attachment name contains	(all)	Only print matching filenames
Ignore attachment names containing	—	Skip filenames containing any configured substring
Only print extensions	(all printable)	Optional allow-list such as `pdf docx jpg`
Ignore extensions	—	Optional deny-list such as `png tiff`
Booklet printing	Off	Reorder pages and force short-edge duplex
Duplex	Two-sided portrait	Fallback duplex mode
Mark as Seen	On	Set `\Seen` flag on the email after processing

Decision logic

imap_content event received
        │
        ├─ folder in folder_filter? (empty = yes) ──── no ──► skip
        │
        ├─ sender in allowed_senders? (empty = yes) ── no ──► skip
        │
        ├─ subject contains filter? (empty = yes) ───── no ──► skip
        ├─ filename / extension rules match? ───────── no ──► skip
        ├─ any printable attachment left? ───────────── no ──► skip
        │
        └─ convert matching attachments to PDF
                 apply mail parameters / blueprint settings
                 merge attachments into one job
                 apply booklet imposition after merge
                 ──► print_bridge.process_imap_message(duplex, booklet)
                 ──► imap.seen  (if mark_as_seen)

Example — multiple rule sets

Automation 1 — Invoices (one-sided, INBOX):

Folder Filter: INBOX
Allowed Senders: billing@mybank.com
One-sided Keywords: INVOICE

Automation 2 — Programmes (booklet, INBOX/Print):

Folder Filter: INBOX/Print
Booklet Keywords: Programme, Bulletin
Default Duplex: Two-sided landscape

Lovelace Audit Dashboard

A paste-ready dashboard view is included at lovelace/printer_dashboard_template.yaml. The fuller audit dashboard is still available at lovelace/print_bridge_audit.yaml.

Add it as a new view to any dashboard (Edit → Add View → Manual Configuration (YAML)). Replace PRINTER_NAME with the slug for your printer queue name.

The view includes:

Status row — printer online, queue depth, jobs sent, last job status
Scheduled Queue table — up to 5 scheduled or printer-busy jobs with filename, sender/settings, and queue time
Logbook card — 7-day print event history
Recent jobs table — last 50 jobs: timestamp / filename / ✅❌ / sender / duplex / booklet
Filter Preview table — folder / subject / sender / ✅match / PDF count
Statistics graph — daily job counts (30 days)
Action buttons — Check Filter, Print Test Page, Clear Queue, Cancel Queued Jobs

Developer Setup

git clone https://github.com/rubeecube/ha-print-bridge
cd ha-print-bridge
chmod +x setup-dev.sh && ./setup-dev.sh

setup-dev.sh activates git hooks (pre-commit + pre-push author checks), sets a repo-local git identity, and creates the Python venv.

# Run tests
./venv/bin/pytest tests/ -v

# Validation stack (HA + GreenMail IMAP + CUPS with cups-pdf)
cd docker && docker compose up -d --build
HA_TOKEN=<token> ./validate.sh

FAQ

Q: Do I need IMAP? A: No. IMAP is only needed for email-triggered printing. Without IMAP, enable Auto Print and put supported files in the configured Print Queue Folder, or call print_bridge.print_file.

Q: Can I print from multiple email addresses?
A: Yes — add one address per line in Allowed Senders, or leave it empty to accept all.

Q: Can I filter by mailbox folder?
A: Yes — add one folder name per line in IMAP Folder Filter (e.g. INBOX/Print). The hint in the Options form shows the exact folder names your IMAP integration monitors. Leave empty to accept all folders.

Q: How do I check which emails would be printed right now?
A: Press the Check Filter button (or call print_bridge.check_filter). Results appear in the sensor.print_bridge_*_filter_preview entity and in the Lovelace audit view.

Q: What if my PDF is very large?
A: Print Bridge calls imap.fetch_part which has no size limit (unlike the 32 KB event body limit).

Q: How do I enable booklet printing?
A: Add a substring of the attachment filename to Booklet Patterns in the options (e.g. Programme). Any matching attachment or merged email job is automatically reordered for saddle-stitch printing.

Q: What happens to the email after it's printed?
A: Configure Email Action after Printing in Options: Mark as read keeps it in your inbox but removes the unread badge; Move to archive folder moves it to INBOX/Printed (or a folder you choose) and marks it read; Delete from server removes it permanently. Default is Do nothing (no change to the email).

Q: How do I get notified when a print job fails?
A: Notify when print fails is enabled by default. A HA persistent notification will appear in the bell (🔔) menu with the filename and error. Enable Notify when print succeeds if you also want confirmation of successful prints.

Q: Do I need to install HA's built-in IPP integration?
A: No. HA's ipp integration (docs) is a printer monitor — it reads ink levels, paper status, and error codes. Print Bridge is its own IPP client: it builds raw IPP/2.0 Print-Job packets and sends them directly to the printer or CUPS server via HTTP POST. The two integrations are independent and can be installed side-by-side.

	HA IPP integration	Print Bridge
Purpose	Monitor printer state (ink, errors)	Send print jobs from email
Protocol	Reads IPP attributes	Writes IPP Print-Job
Required for printing	No	Yes
Useful together	Yes — monitors the same printer	Yes — sends jobs to same printer

Print Bridge is separate because print submission, attachment conversion, booklet imposition, queueing, retries, and sender status replies are outside the scope of HA's printer-monitoring integration.

Q: Do I need CUPS at all?
A: Not for modern AirPrint printers. If your printer has an IPP endpoint (most WiFi printers made after ~2015 do), use Direct IPP mode with a URL like http://printer.local/ipp/print. CUPS is useful when the printer is USB-attached, needs format conversion (PCL/PostScript), or you want a managed queue.

Q: How do I find my printer's IPP URL?
A: Common paths: http://printer.local/ipp/print, http://printer.local:631/ipp/print, or the same paths with your printer host name. Your router's device list shows the printer's network name. For Canon PIXMA: the embedded server is usually at port 80 with path /ipp/print.

Q: CUPS is on a different host. What URL do I use?
A: http://<cups-host>:631. When using the CUPS add-on on HA OS with host networking, the host can be your HA host name.

Contributing

Pull requests are welcome. Please open an issue first for significant changes.

./venv/bin/pytest tests/ -v   # 205 tests, no external dependencies required

Name		Name	Last commit message	Last commit date
Latest commit History 70 Commits
.githooks		.githooks
.github/workflows		.github/workflows
blueprints/automation/print_bridge		blueprints/automation/print_bridge
custom_components		custom_components
docker		docker
home-assistant		home-assistant
lovelace		lovelace
tests		tests
.gitignore		.gitignore
CHANGELOG.md		CHANGELOG.md
LICENSE		LICENSE
README.md		README.md
hacs.json		hacs.json
hacs.png		hacs.png
pyproject.toml		pyproject.toml
requirements-test.txt		requirements-test.txt
setup-dev.sh		setup-dev.sh

Folders and files

Latest commit

History

Repository files navigation
