WorldTrace

WorldTrace is a cross-platform Flutter travel journal designed to feel like a personal travel atlas. It combines an interactive world map, diary-style trip timelines, stats and goals, achievements, and shareable recaps. The app is offline-first: data is stored locally on the device (SQLite + shared_preferences), and guest mode is the default. The codebase is structured to allow a future remote database/backend and real auth providers, but those are not implemented yet.

This README is a complete developer reference for what is implemented today, what is stubbed, and what is still in progress.

Table of contents

• Overview
• Quick start
• Emulator testing
• Project structure
• Architecture and data flow
• Database schema
• Models
• Repositories
• Services
• Widgets
• Screens and navigation
• Maps and geo
• Media and sharing
• Localization
• Tests
• In progress and TODO
• Known limitations
• License and collaboration

Overview

Implemented today (high-level):

• Trip journal with steps, notes, dates, and local media.
• Interactive world map with visited-country highlighting and a country detail sheet.
• Stats dashboard, goals, achievements, and travel profile summary.
• Trip Story and Year in Review shareable cards.
• Media gallery and full-screen photo viewer on mobile/desktop.
• Guest-only auth (local only) with profile editing in Settings. The email/Google/Facebook buttons are UI placeholders only.
• Free vs Pro plan mock with step limits and upgrade screen.

Implemented today (feature depth):

• Trips
  • Create, edit, delete trips with date range, country ISO, title, notes.
  • Timeline grouped by day with step cards.
  • Trip-level gallery and shareable story.
• Steps
  • Diary-style text entries with optional place name and timestamp.
  • Attach photos from device storage.
  • View and share step details.
• Map
  • GeoJSON-driven world map with tap-to-select country.
  • Country sheet showing stats and recent trips.
  • Visited-country set and intensity calculations (currently not applied to fill color).
• Stats and goals
  • Totals (trips, countries, days), per-year summaries.
  • Longest trip, average days per trip.
  • Goal creation and progress tracking (countries per year).
• Achievements
  • Unlocks based on trip count, countries, and travel days.
• Recaps and sharing
  • Trip Story share card (image capture via RepaintBoundary).
  • Year in Review with highlights, map, and shareable card.
  • "On this day" memory surface.
• Media and profiles
  • Media gallery by trip, full-screen viewer, share for photos.
  • Guest profile with name, birthdate, avatar stored locally.

Not implemented yet (see In progress and TODO):

• Firebase auth integration and real provider sign-in flows (buttons are placeholders only).
• Billing and real Pro entitlements.
• Guest to account migration.
• Step geolocation input and true map-based step capture.

Testing status:

• Tested only on Android devices/emulators to date.

Quick start

Prerequisites:

• Flutter SDK installed.
• flutter doctor has no critical errors for your target platform.

Install deps and run:

flutter pub get
flutter run -d <device_id>

Emulator testing

Android emulator (Windows/macOS/Linux):

1. Install Android Studio and the Android SDK.
2. Open Android Studio -> Device Manager -> Create a new virtual device (AVD).
3. From the terminal, list emulators:

   flutter emulators

4. Launch an emulator by id:

   flutter emulators --launch <emulator_id>

5. Run the app on that emulator:

   flutter run -d <emulator_id>

Web (not an emulator, but useful for quick UI checks):

flutter run -d chrome

Desktop (optional):

flutter run -d windows
flutter run -d macos
flutter run -d linux

Note: Map tiles are loaded from online providers, so an internet connection is required to see base maps.

Project structure

lib/
  app.dart                 # MaterialApp, routes, localization setup
  main.dart                # bootstrap + Provider wiring
  firebase_init.dart       # Firebase init (currently disabled)
  theme/app_theme.dart     # theme, ColorScheme, GlassTheme
  models/                  # Trip, Step, Goal, Achievement, YearReview, etc.
  repositories/            # Trip, Step, Goal repositories
  services/                # DB, auth, stats, geo, plan, year review
  screens/                 # UI screens
  widgets/                 # shared UI components
  utils/                   # helpers for map intensity, flags, photo viewer
assets/geojson/            # world map polygons
test/                      # unit and widget tests

Platform folders are present for Android, iOS, macOS, Windows, Linux, and Web. The app is currently Android-first; iOS is not maintained or tested.

Tech stack

Core:

• Flutter (Dart), Material 3
• Provider for state management
• SQLite via sqflite
• shared_preferences for lightweight local settings/profile

Maps and geo:

• flutter_map + latlong2
• GeoJSON assets (assets/geojson/world_simplified.geojson)

Media and sharing:

• image_picker for photos
• share_plus for text and image sharing

Localization and UI:

• intl + Flutter localizations
• google_fonts for typography
• sign_in_button for provider button styling (UI-only placeholders)

Backend placeholder:

• firebase_core is included but initialization is disabled.

Architecture and data flow

• State management: Provider.
• Data flow:
  • UI screens call repositories/services.
  • Repositories read/write SQLite via DbService.
  • Services compute aggregates (stats, goals, achievements, year review).
  • Maps are rendered from GeoJSON via GeoService and WorldMap.

Bootstrap:

• main.dart initializes Flutter bindings, calls FirebaseInit.init(), initializes the DB, and registers Providers.
• app.dart defines the app theme, supported locales, and named routes.

Database schema

SQLite database worldtrace.db is created in DbService (lib/services/db_service.dart). Current schema version is 2.

Tables:

• trips
  • id INTEGER PRIMARY KEY AUTOINCREMENT
  • userId TEXT
  • countryIsoCode TEXT
  • startDate TEXT (ISO 8601)
  • endDate TEXT (ISO 8601)
  • tripType TEXT
  • title TEXT
  • notes TEXT
• trip_steps
  • id TEXT PRIMARY KEY
  • tripId TEXT NOT NULL
  • timestamp TEXT NOT NULL (ISO 8601)
  • latitude REAL NULL
  • longitude REAL NULL
  • placeName TEXT NULL
  • text TEXT NOT NULL
  • mediaPaths TEXT NULL (comma-separated file paths)
• memories (not currently used in UI)
  • id INTEGER PRIMARY KEY AUTOINCREMENT
  • tripId INTEGER
  • type TEXT
  • path TEXT
  • caption TEXT
  • createdAt TEXT (ISO 8601)
• goals
  • id TEXT PRIMARY KEY
  • userId TEXT NOT NULL
  • title TEXT NOT NULL
  • type TEXT NOT NULL
  • targetValue INTEGER NOT NULL
  • year INTEGER NOT NULL
  • createdAt TEXT NOT NULL
  • updatedAt TEXT NOT NULL

Migration behavior:

• Version 2 drops and recreates goals if upgrading from older versions.

Models

Active models:

• TripModel: id, userId, countryIsoCode, startDate, endDate, tripType, title, notes.
• StepModel: id (String), tripId, timestamp, latitude, longitude, placeName, text, mediaPaths.
• GoalModel: id, userId, title, type, targetValue, year, createdAt, updatedAt.
• Achievement: id, title, description, unlocked.
• YearReview: year, tripsCount, countriesCount, totalDays, longestTrip, topCountry, achievements, highlightSteps.
• UserProfile: firstName, lastName, birthDate, photoPath.
• OnThisDayMemory: trip, step, year, countryName, flagEmoji, photoPath.

Present but not currently wired into UI flows:

• MemoryModel (memories table exists but no repository or screen usage).
• CountryModel
• AppUserModel
• UserModel

Repositories

• TripRepository / LocalTripRepository
  • Add/update/delete trips
  • Get trips by user
  • Compute days per country
  • Delete trip with cascading step deletion
• StepRepository
  • Add/update/delete steps
  • Get steps for a trip or multiple trips
• GoalRepository
  • Add/update/delete goals
  • Fetch goals by user

Services

• DbService: database init, schema, CRUD helpers, trip deletion with steps.
• AuthService: guest-only auth; stores guest id in shared_preferences.
  • Email/Google/Apple sign-in methods throw UnsupportedError (stubbed); UI buttons are placeholders.
• PlanService: Free vs Pro (mocked). Free limit is 10 steps per trip. upgradeToProMock() toggles Pro.
• StatsService: totals and highlights:
  • total trips, countries, travel days
  • days by year
  • average days per trip
  • longest and most recent trip
  • goal progress for countries-per-year
• AchievementsService: unlocks based on stats (first trip, 5 trips, 10 trips, 5 countries, 10 countries, 30 days in a year, 100 total days).
• GeoService: loads GeoJSON, caches country geometry, hit-testing for taps.
• YearReviewService: builds year recap data with top country, longest trip, highlights, and achievements.
• OnThisDayService: builds memories for today based on step timestamps.
• UserProfileService: stores profile data in shared_preferences per user id.
• FirebaseInit: currently disabled, prints a debug message.

Widgets

• WorldMap: renders polygons via flutter_map, supports tap to select countries and display labels. Uses GeoJSON data and online tile layers.
• CountryOverviewSheet: bottom sheet with country stats, last visit, and photo strip.
• GlassPanel: reusable glassmorphism container with blur and gradient.
• StatsCard: small stat cards used on Home and Stats screens.

Screens and navigation

Routes are declared in lib/app.dart:

• /home -> HomeScreen
• /trips -> TripsListScreen
• /stats -> StatsScreen
• /goals -> GoalsScreen
• /settings -> SettingsScreen
• /profile -> TravelProfileScreen
• /world-map -> WorldMapScreen
• /achievements -> AchievementsScreen
• /year-review -> YearInReviewScreen

Other screens are pushed via MaterialPageRoute in the UI:

• TripDetailScreen, TripEditScreen, StepEditScreen, StepDetailScreen, StepMediaViewerScreen, TripStoryScreen, MediaGalleryScreen, UpgradeScreen.

Screen details:

• AuthScreen: guest-only login; email/Google/Facebook buttons are UI placeholders.
• OnboardingScreen: static 3-page intro with "Continue as guest"; not wired to routes.
• HomeScreen:
  • Gradient background, map hero, stats rail, "On this day" memory.
  • Drawer with navigation.
  • Uses WorldMap and CountryOverviewSheet for tap details.
  • Pull-to-refresh reloads trips, steps, and map geometries.
• TripsListScreen:
  • Lists all trips (or a filtered country).
  • Shows country flag, title, date range, day count.
  • Allows delete with confirmation dialog.
• TripEditScreen:
  • Form for trip title, country ISO, notes, date range.
  • Validates required fields and date order.
• TripDetailScreen:
  • Header with date range, country, notes.
  • Optional map with step markers (requires step lat/lon).
  • Trip-level photo gallery.
  • Timeline grouped by day with step cards.
  • Step actions: view, edit, delete, share story.
  • Free/Pro gating: step limit with upgrade flow.
• StepEditScreen:
  • Diary-style editor for text, date/time, place name.
  • Adds photos with image_picker (disabled on web).
  • Does not capture coordinates (lat/lon remain null).
• StepDetailScreen:
  • Read-only diary view, share text via Share Plus.
  • Photo strip with full-screen viewer.
• StepMediaViewerScreen:
  • Full-screen photo viewer with paging and share action.
  • Only works with local files; web shows placeholders.
• WorldMapScreen:
  • Full-screen world map with visited countries.
  • Country tap opens CountryOverviewSheet.
  • FAB creates new trip.
• MediaGalleryScreen:
  • Grid of trips with a cover photo (first media found per trip).
  • Empty state when no media exists.
• StatsScreen:
  • Summary stats cards and highlights panel.
  • Signed-out state shows CTA to auth.
• GoalsScreen:
  • Create goals (countries per year).
  • Progress computed via StatsService.
  • Delete goal action.
• AchievementsScreen:
  • List of achievement tiles (locked/unlocked).
• TravelProfileScreen:
  • Summary card with totals and top year.
  • Achievements count, goals overview, plan status.
  • Link to Year in Review and Gallery.
  • Share button shares text stats (not image).
• YearInReviewScreen:
  • Year selection chips.
  • Map with travel path and country markers.
  • Story card built via RepaintBoundary and shared as image.
  • Achievements list and photo mosaic.
• SettingsScreen:
  • Profile edit dialog (name, birthdate, avatar photo).
  • Plan status card, logout.
  • Copyright notice at bottom.
• UpgradeScreen:
  • Mock upgrade flow; toggles Pro plan in PlanService.

Maps and geo

Map stack:

• Polygons from assets/geojson/world_simplified.geojson.
• GeoJSON parsing in GeoService.
• Map UI in WorldMap widget.

Tile providers:

• Home map and Year in Review map use ArcGIS tiles:
  • World Imagery and World Street Map endpoints.
• Trip story map uses OpenStreetMap tiles.
• Network connection is required for tiles.

Country selection:

• WorldMap uses a hit-test on cached polygons and calls a tap callback.
• CountryOverviewSheet shows stats and photo previews.

Intensity:

• IntensityUtils normalizes days by country and provides discrete levels.
• WorldMap currently does not use intensity to vary fill color; visited countries are filled with a single style.

Map integration notes:

• See MAP_INTEGRATION_V2.md for the current GeoJSON parsing and map rendering pipeline.

Media and sharing

Media:

• Photos are selected via image_picker.
• Paths are stored in DB as comma-separated strings.
• The app does not copy files; it relies on original device paths.
• Web: full-screen viewing and image picking are disabled; placeholders are shown.

Sharing:

• Text share in StepDetailScreen and TravelProfileScreen.
• Image share in TripStoryScreen and YearInReviewScreen via RepaintBoundary.
• Desktop/mobile use temporary files; web uses in-memory bytes.

Localization

• ARB files under lib/l10n/ with generated Dart in lib/l10n/app_localizations.dart.
• Supported locales declared in lib/app.dart:
  • en, it, fr, es, de, pt, ja, ru, zh, hi
• Regenerate localizations after editing ARB:

flutter gen-l10n

Tests

Run tests:

flutter test

Tests included:

• test/days_calc_test.dart: TripModel day count.
• test/stats_service_test.dart: StatsService aggregates and per-year split.
• test/intensity_utils_test.dart: normalization and level mapping.
• test/goal_progress_test.dart: simple goal progress check (standalone).
• test/widget_test.dart: smoke test for app build with fake repositories.

In progress and TODO

Explicitly stubbed or disabled:

• Firebase auth initialization is disabled (lib/firebase_init.dart).
• Email/Google/Apple sign-in methods are stubbed in AuthService.
• Pro upgrade is mocked in PlanService.

Planned or incomplete flows:

• Guest to account migration flow.
• Real billing and entitlements.
• Step coordinate capture (lat/lon) in the Step editor.
• Map intensity shading based on days (data is computed but not applied).
• Onboarding screen is not wired into navigation.
• Memories table and MemoryModel are not wired to any UI.
• Several models (CountryModel, UserModel, AppUserModel) are unused.

Known limitations

• No cloud sync, no backend, local-only data.
• Web build cannot access local file paths for photo viewer.
• Map tiles require network access and may fail offline.
• Login provider buttons are UI-only; only guest access works.
• Goal migration drops goals when upgrading from DB version < 2.
• iOS is not actively supported or tested.

License and collaboration

This repository uses a proprietary collaboration license. You may use it only to collaborate on the WorldTrace app with the copyright holder. Reproduction or monetization without explicit permission is prohibited. See LICENSE for full terms.
